What is Silica?

Silicon dioxide, also known as silica (from the Latin silex), is a chemical compound that is an oxide of silicon with the chemical formula SiO2. It has been known since ancient times. Silica is most commonly found in nature as sand or quartz, as well as in the cell walls of diatoms.

Silica is manufactured in several forms including fused quartz, crystal, fumed silica (or pyrogenic silica), colloidal silica, silica gel, and aerogel.

Silica is used primarily in the production of glass for windows, drinking glasses, beverage bottles, and many other uses. The majority of optical fibers for telecommunications are also made from silica. It is a primary raw material for many ceramics such asearthenware, stoneware, and porcelain.

Silica is a common additive in the production of foods, where it is used primarily as a flow agent in powdered foods, or to absorb water in hygroscopic applications. It is the primary component of diatomaceous earth, which has many uses ranging from filtration to insect control. It is also the primary component of rice husk ash, which is used, for example, in filtration and cement manufacturing.

Thin films of silica grown on silicon wafers via thermal oxidation methods can be quite beneficial in microelectronics, where they act as electric insulators with high chemical stability. In electrical applications, it can protect the silicon, store charge, block current, and even act as a controlled pathway to limit current flow.

A silica-based aerogel was used in the Stardust spacecraft to collect extraterrestrial particles. Silica is also used in the extraction of DNA and RNA due to its ability to bind to the nucleic acids under the presence of chaotropes. As hydrophobic silica it is used as a defoamer component. In hydrated form, it is used in toothpaste as a hard abrasive to remove tooth plaque.

In its capacity as a refractory, it is useful in fiber form as a high-temperature thermal protection fabric. In cosmetics, it is useful for its light-diffusing properties and natural absorbency. Colloidal silica is used as a wine and juice fining agent. In pharmaceutical products, silica aids powder flow when tablets are formed. It is also used as a thermal enhancement compound in ground source heat pump industry.

Lamellar Quartz and Lower VOCs

Low Oil Absorption = Lower VOCs

One of the greatest features of Novacite® is the ability to lower VOCs. The low oil absorption of the lamellar quartz silica is 17-20 from our coarsest to finest grades, respectively. In fact, Novacite® ranks 2nd only behind barytes. The low oil absorption allows for higher pigment loading.

Higher PVC without Higher Viscosity

Due to the unique, lamellar shape, formulators can increase PVC without impacting rheology or increasing viscosity. The platy shape and low oil absorption allow the pigment to flow even as particle size distribution is decreased and particle-particle interaction is increased.

Similar shaped pigments, such as lamellar talc and mica possess high oil absorption properties which negatively impacts viscosity. Novacite® is an ideal extender pigment when cost reduction and lowering VOCs are the desired outcome.
